공간 보간 기법 중 하나인 Kriging 을 R에서는 사용하기 편리하기 위해서 automap패키지에서 autoKrige로 지원하고 있다. 하지만 최근 fitting 과정에서 fit.method가 gstats 패키지에 있어 옵션이 수정되지 않는 현상을 겪었다.

따라서 아래와같이 function을 올려보겠다.

autoKrige2=function (formula, input_data, new_data, data_variogram = input_data,
                     block = 0, model = c("Sph", "Exp", "Gau", "Ste"), kappa = c(0.05,
                                                                                 seq(0.2, 2, 0.1), 5, 10), fix.values = c(NA, NA, NA),
                     remove_duplicates = TRUE, verbose = FALSE, GLS.model = NA, fit.method=fit.method,
                     start_vals = c(NA, NA, NA), miscFitOptions = list(), ...)
{
  if (inherits(formula, "SpatialPointsDataFrame")) {
    input_data = formula
    formula = as.formula(paste(names(input_data)[1], "~ 1"))
  }
  if (!inherits(input_data, "SpatialPointsDataFrame") | !inherits(data_variogram,
                                                                  "SpatialPointsDataFrame")) {
    stop(paste("\nInvalid input objects: input_data or data_variogram not of class 'SpatialPointsDataFrame'.\n\tClass input_data: '",
               class(input_data), "'", "\n\tClass data_variogram: '",
               class(data_variogram), "'", sep = ""))
  }
  if (as.character(formula)[3] != 1 & missing(new_data))
    stop("If you want to use Universal Kriging, new_data needs to be specified \n  because the predictors are also required on the prediction locations.")
  if ("newdata" %in% names(list(...)))
    stop("The argument name for the prediction object is not 'newdata', but 'new_data'.")
  if (remove_duplicates) {
    zd = zerodist(input_data)
    if (length(zd) != 0) {
      warning("Removed ", length(zd)/2, " duplicate observation(s) in input_data:",
              immediate. = TRUE)
      print(input_data[c(zd), ])
      input_data = input_data[-zd[, 2], ]
    }
  }
  col_name = as.character(formula)[2]
  if (length(unique(input_data[[col_name]])) == 1)
    stop(sprintf("All data in attribute '%s' is identical and equal to %s\n   Can not interpolate this data",
                 col_name, unique(input_data[[col_name]])[1]))
  if (missing(new_data))
    new_data = create_new_data(input_data)
  p4s_obj1 = proj4string(input_data)
  p4s_obj2 = proj4string(new_data)
  if (!all(is.na(c(p4s_obj1, p4s_obj2)))) {
    if (is.na(p4s_obj1) & !is.na(p4s_obj2))
      proj4string(input_data) = proj4string(new_data)
    if (!is.na(p4s_obj1) & is.na(p4s_obj2))
      proj4string(new_data) = proj4string(input_data)
    if (any(!c(is.projected(input_data), is.projected(new_data))))
      stop(paste("Either input_data or new_data is in LongLat, please reproject.\n",
                 "  input_data: ", p4s_obj1, "\n", "  new_data:   ",
                 p4s_obj2, "\n"))
    if (proj4string(input_data) != proj4string(new_data))
      stop(paste("Projections of input_data and new_data do not match:\n",
                 "  input_data: ", p4s_obj1, "\n", "  new_data:    ",
                 p4s_obj2, "\n"))
  }

  variogram_object = autofitVariogram2(formula, data_variogram,
                                       model = model, kappa = kappa, fix.values = fix.values,
                                       verbose = verbose, GLS.model = GLS.model, start_vals = start_vals,
                                       miscFitOptions = miscFitOptions, fit.method =fit.method)
  krige_result = krige(formula, input_data, new_data, variogram_object$var_model,
                       block = block, ...)
  krige_result$var1.stdev = sqrt(krige_result$var1.var)
  result = list(krige_output = krige_result, exp_var = variogram_object$exp_var,
                var_model = variogram_object$var_model, sserr = variogram_object$sserr)
  class(result) = c("autoKrige", "list")
  return(result)
}
autofitVariogram2=function (formula, input_data, model = c("Sph", "Exp", "Gau",
                                                           "Ste"), kappa = c(0.05, seq(0.2, 2, 0.1), 5, 10), fix.values = c(NA,
                                                                                                                            NA, NA), verbose = FALSE, GLS.model = NA, start_vals = c(NA,
                                                                                                                                                                                     NA, NA), miscFitOptions = list(),fit.method = 1, ...)
{
  if ("alpha" %in% names(list(...)))
    warning("Anisotropic variogram model fitting not supported, see the documentation of autofitVariogram for more details.")
  miscFitOptionsDefaults = list(merge.small.bins = TRUE, min.np.bin = 5)
  miscFitOptions = modifyList(miscFitOptionsDefaults, miscFitOptions)
  longlat = !is.projected(input_data)
  if (is.na(longlat))
    longlat = FALSE
  diagonal = spDists(t(bbox(input_data)), longlat = longlat)[1,
                                                             2]
  boundaries = c(2, 4, 6, 9, 12, 15, 25, 35, 50, 65, 80, 100) *
    diagonal * 0.35/100
  if (!is(GLS.model, "variogramModel")) {
    experimental_variogram = variogram(formula, input_data,
                                       boundaries = boundaries, ...)
  }
  else {
    if (verbose)
      cat("Calculating GLS sample variogram\n")
    g = gstat(NULL, "bla", formula, input_data, model = GLS.model,
              set = list(gls = 1))
    experimental_variogram = variogram(g, boundaries = boundaries,
                                       ...)
  }
  if (miscFitOptions[["merge.small.bins"]]) {
    if (verbose)
      cat("Checking if any bins have less than 5 points, merging bins when necessary...\n\n")
    while (TRUE) {
      if (length(experimental_variogram$np[experimental_variogram$np <
                                           miscFitOptions[["min.np.bin"]]]) == 0 | length(boundaries) ==
          1)
        break
      boundaries = boundaries[2:length(boundaries)]
      if (!is(GLS.model, "variogramModel")) {
        experimental_variogram = variogram(formula,
                                           input_data, boundaries = boundaries, ...)
      }
      else {
        experimental_variogram = variogram(g, boundaries = boundaries,
                                           ...)
      }
    }
  }
  if (is.na(start_vals[1])) {
    initial_nugget = min(experimental_variogram$gamma)
  }
  else {
    initial_nugget = start_vals[1]
  }
  if (is.na(start_vals[2])) {
    initial_range = 0.1 * diagonal
  }
  else {
    initial_range = start_vals[2]
  }
  if (is.na(start_vals[3])) {
    initial_sill = mean(c(max(experimental_variogram$gamma),
                          median(experimental_variogram$gamma)))
  }
  else {
    initial_sill = start_vals[3]
  }
  if (!is.na(fix.values[1])) {
    fit_nugget = FALSE
    initial_nugget = fix.values[1]
  }
  else fit_nugget = TRUE
  if (!is.na(fix.values[2])) {
    fit_range = FALSE
    initial_range = fix.values[2]
  }
  else fit_range = TRUE
  if (!is.na(fix.values[3])) {
    fit_sill = FALSE
    initial_sill = fix.values[3]
  }
  else fit_sill = TRUE
  getModel = function(psill, model, range, kappa, nugget,
                      fit_range, fit_sill, fit_nugget, verbose) {
    if (verbose)
      debug.level = 1
    else debug.level = 0
    if (model == "Pow") {
      warning("Using the power model is at your own risk, read the docs of autofitVariogram for more details.")
      if (is.na(start_vals[1]))
        nugget = 0
      if (is.na(start_vals[2]))
        range = 1
      if (is.na(start_vals[3]))
        sill = 1
    }
    obj = try(gstat::fit.variogram(experimental_variogram, model = vgm(psill = psill,
                                                                       model = model, range = range, nugget = nugget, kappa = kappa),
                                   fit.ranges = c(fit_range), fit.sills = c(fit_nugget,
                                                                            fit_sill), debug.level = 0,fit.method = fit.method), TRUE)
    if ("try-error" %in% class(obj)) {
      warning("An error has occured during variogram fitting. Used:\n",
              "\tnugget:\t", nugget, "\n\tmodel:\t", model,
              "\n\tpsill:\t", psill, "\n\trange:\t", range,
              "\n\tkappa:\t", ifelse(kappa == 0, NA, kappa),
              "\n  as initial guess. This particular variogram fit is not taken into account. \nGstat error:\n",
              obj)
      return(NULL)
    }
    else return(obj)
  }
  test_models = model
  SSerr_list = c()
  vgm_list = list()
  counter = 1
  for (m in test_models) {
    if (m != "Mat" && m != "Ste") {
      model_fit = getModel(initial_sill - initial_nugget,
                           m, initial_range, kappa = 0, initial_nugget,
                           fit_range, fit_sill, fit_nugget, verbose = verbose)
      if (!is.null(model_fit)) {
        vgm_list[[counter]] = model_fit
        SSerr_list = c(SSerr_list, attr(model_fit, "SSErr"))
      }
      counter = counter + 1
    }
    else {
      for (k in kappa) {
        model_fit = getModel(initial_sill - initial_nugget,
                             m, initial_range, k, initial_nugget, fit_range,
                             fit_sill, fit_nugget, verbose = verbose)
        if (!is.null(model_fit)) {
          vgm_list[[counter]] = model_fit
          SSerr_list = c(SSerr_list, attr(model_fit,
                                          "SSErr"))
        }
        counter = counter + 1
      }
    }
  }
  strange_entries = sapply(vgm_list, function(v) any(c(v$psill,
                                                       v$range) < 0) | is.null(v))
  if (any(strange_entries)) {
    if (verbose) {
      print(vgm_list[strange_entries])
      cat("^^^ ABOVE MODELS WERE REMOVED ^^^\n\n")
    }
    warning("Some models where removed for being either NULL or having a negative sill/range/nugget, \n\tset verbose == TRUE for more information")
    SSerr_list = SSerr_list[!strange_entries]
    vgm_list = vgm_list[!strange_entries]
  }
  if (verbose) {
    cat("Selected:\n")
    print(vgm_list[[which.min(SSerr_list)]])
    cat("\nTested models, best first:\n")
    tested = data.frame(`Tested models` = sapply(vgm_list,
                                                 function(x) as.character(x[2, 1])), kappa = sapply(vgm_list,
                                                                                                    function(x) as.character(x[2, 4])), SSerror = SSerr_list)
    tested = tested[order(tested$SSerror), ]
    print(tested)
  }
  result = list(exp_var = experimental_variogram, var_model = vgm_list[[which.min(SSerr_list)]],
                sserr = min(SSerr_list))
  class(result) = c("autofitVariogram", "list")
  return(result)
}
